NXanxe

Features

  • DSP Power Factor Corrected IGBT Rectifier
  • DSP Controlled IGBT Inverter
  • True On-Line Double Conversion UPS
  • DSP control
  • Extended Load Ranges
  • Leading Power Factor



Type dan Kapasitas


  • Nxa 30 – 30 KVA (24 KW)
  • Nxa 40 – 40 KVA (32 KW)
  • Nxa 60 – 60 KVA (48 KW)
  • Nxa 80 – 80 KVA (64 KW)
  • Nxa 100 – 100 KVA (80 KW)
  • Nxa 120 – 120 KVA (96 KW)
  • Nxa 140 – 140 KVA (112 KW)
  • Nxa 160 – 160 KVA (128 KW)
  • Nxa 200 – 200 KVA (160 KW)
Teknologi : On Line full IGBT (rec & inv)
Input Voltage Range : 380/400/415 (Accepted from 305 to 447 without batt.use)
Input Frequency : 50 or 60 Hz (Accepted range from 40 to 70)
Input THD : <3% (without any filter)
Input power factor : >0,99 (without any filter)
Output Voltage : 380 / 400 / 415 +/- 0.5 Regulation (3-phase RMS average)
Output Frequency : 50 or 60Hz, +/- 0,05% regulation
Output THD : 1% (max)
Overload Capability : 110% for 60 minutes
  125% for 10 minutes
  150% for 1 minute
Back Up Time : ± 10 Menit
Output Power :  0.8

View NXe & NXa (585.00KB) brochure.
